220-240V 10W LED reflektor Downlight bílý 6000K , VT-2610

Product evaluation Favourite Comparison Send to email Whole product group E-shop
Order number: SKU1100
Brand: V-TAC
Type / Description: LED Downlight COB Reflektor
Jmenovité napětí (V):220 - 240
Nominal wattage:10
Colour temperature:6000
Colour rendering index CRI:> 80
Luminous flux:730
Lamp efficacy:73
Unit EAN13 code: 3800230622372

Download

Technical sheet

Technical drawing not available


Download

Technical sheet

Technical sheet 220-240V 10W LED reflektor Downlight bílý 6000K , VT-2610


Wiring Diagram not available


General information

Finish Recessed
Brand/Manufacturer V-TAC
Material PKW
Dimmable Ne
Energy efficiency class (canceled regulation!) A+
Nominal voltage (V) 220 - 240 V
Degree of protection (IP) IP20
Název položky LED Downlight COB Reflektor
Skupina produktu V-TAC VT-2610

Working conditions

Temperature -0,444444444 °C

Physical characteristics

Type of chip COB
Width 71 mm
Weight netto 450 g
Diameter 135 mm
Počet ks v balení 1
Tvar V-TAC Round
Barva tělesa V-TAC White
Počet kusů v kartonu 27

Lighting characteristics

Luminous flux 730 lm
Colour temperature 6000 K
Radiation angle 120 °
Colour rendering index CRI 80 Ra
Barva světla White

Energetic characteristics

Lamp Power factor (PF) >0.9
Lamp efficacy 73 lm/W

Electrical characteristics

Nominal wattage 10 W
Frequency 50 Hz

Mounting methods/application

Dimensions of installation hole 105 mm

EuP Parameters

Number of maximal switching cycles 15000
Rated service life 20000 h
Turn-on time 0.001 sec (instant on) s
GLS replacement 25 W

Safety information

Product certification CE, EMC, ROHS
