Order number: | 222006 |
Brand: | NBB |
Type / Description: | Kompaktní zářivka |
Jmenovitý proud: | 0,2 |
Nominal wattage: | 18 |
Light Colour: | Chladná denní |
Colour temperature: | 6500 |
Colour rendering index CRI: | > >80 Ra8 |
Luminous flux: | 1270 |
Lamp efficacy: | 70,55 |
Unit EAN13 code: | 8595209908957 |
ILCOS: | FSQ-18/65/1B-I-G24d=2 |
Threephosphore 2-pin compact fluorescent lamps. Colour temperature 6500 K.
Changes to data are subject to prior notice. NBB Bohemia s.r.o. accepts no responsibility for damages caused by inaccurate interpretation of the content on this site.
When replacing a fluorescent tube, first disconnect the luminaire from the electrical current supply. First remove the fluorescent lamp from the fixture and then install a new one. Take care to ensure that the product is not broken. Install the new fluorescent lamp by gently inserting it and turning it into the sides of the luminaire to any side. Only use the product in the luminaires designed for this type of light source. The manufacturer can not be held responsible for damages resulting from inappropriate connection, connection to an unsuitable distribution system, or damage resulting from the use of an unsuitable light source. Observe the operating values on the product. Do not expose the product to inappropriate weathering or high temperatures unless it is expressly stated that the product is intended to be operated under these conditions. When installing, wiring or disassembling, follow the generally accepted safety precautions. After installing a new fluorescent lamp, close the enclosure with original covers - to prevent possible electric shock. Only then connect the luminaire to the electrical circuit.
More photos available
Technical drawing not available
Wiring Diagram not available
Model/Description | Kompaktní zářivka |
Finish | Dvoupinová |
Brand/Manufacturer | NBB |
Nominal service life (h) | 12000 h |
Dimmable | Ne |
Dimmable by conventional dimmers | Ne |
Název položky | KLD-D 18W/865 G24d-2 NBB |
Třída energetické účinnosti podle 2019/2015 | G |
Operating frequency | 50 - 60 Hz |
Burning position | Libovolná |
Suitable for domestic use. | Ano |
Application | Pro všeobecné osvětlování |
Ambient temperature | 25 °C |
Average Lifetime B50 (h) | 12000 h |
Luminescence Life maintenance factor | 70,0 % |
Time to 60 % luminous flux | 60 s |
Number of maximal switching cycles | 15000 |
The rate of premature failures | < 1 % |
Rated service life | 12000 h |
Energy consumption (AGGR) | 18 kWh/1000h |
Safety instructions | www.nbb.cz |
Rated efficiency after 100h | 99,99 % |
Lamp efficacy (lm/W) | 63,88 lm/W |
Lamp efficacy | 70,55 lm/W |
LLMF after 2.000 hrs | 85,0 % |
LLMF after 4.000 hrs | 78,0 % |
LLMF after 6.000 hrs | 73,0 % |
LLMF after 8.000 hrs | 73,0 % |
LLMF after 10.000 hrs | 70,0 % |
Nominal wattage | 18 W |
Rated power (W) | 18,0 W |
Operating voltage (V) | 100 V |
Type of Voltage | AC |
Direct connection to the mains | Ne |
Ignitor | Glow starter |
Nominal current (A) | 0,2 A |
Total power (W) (light fitting) | 18 W |
Dimensions (mm) | 34 x 34 x 155 mm |
Packing method | 10 - 1 |
Weight gross | 75 g |
Weight netto | 60 g |
Type of spectrum | Třípásmové |
Color rendering | 1B |
Light Colour | Chladná denní |
Dominant wavelength | 612 nm |
Luminous flux | 1270 lm |
Colour temperature | 6500 K |
Colour rendering index CRI | >80 Ra8 Ra |
Colour of light | 865 |
Chromaticity coordinates x | 0,341 |
Chromaticity coordinates y | 0,323 |
Mercury content | 3,50 mg |
LSF after 2.000 hrs | 98,2 % |
LSF after 4.000 hrs | 96,3 % |
LSF after 6.000 hrs | 87,0 % |
LSF after 8.000 hrs | 87,0 % |
LSF after 10.000 hrs | 50,0 % |
