Order number: 105154840
Brand: NBB
Type / Description: Třípásmová lineární zářivka T5
Jmenovitý proud:0,46
Nominal wattage:54
Light Colour:Chladná bílá
Colour temperature:4000
Colour rendering index CRI:> 84
Luminous flux:5000
Lamp efficacy:92,4
Unit EAN13 code: 8595209950604
ILCOS: FDH-54/40/1B-L/P-G5-16/1149

Exclusion of liability

Changes to data are subject to prior notice. NBB Bohemia s.r.o. accepts no responsibility for damages caused by inaccurate interpretation of the content on this site.

Warning

If broken in a closed room, we recommend ventilation to reduce the mercury vapor concentration. Use protective equipment while working. Immediately remove the shards so that they do not get injured. After removing the shards, use the technical means for decontamination of mercury. For this purpose we supply decontamination kits, which you can order by phone or in our internet shop. The decontamination kit should not be missed especially in plants where there is a danger of breaking light sources containing mercury, such as stores, warehouses, but can also be used in households. In case of nausea, give first aid and call a physician.

Notice

Fluorescent tubes of all types require a corresponding type of ballast to operate. A suitable ballast type can be found in the detail of the item (additional products). The quality and type of the ballast greatly affect the life of the fluorescent lamp. NBB Bohemia is not responsible for shortening lamp life when the fluorescent lamp is connected to a ballast type that NBB Bohemia s.r.o. because in such a case we can not guarantee the suitability of using the ballast to the supplied fluorescent tube. When directly connected to the mains voltage without using the ballast, the fluorescent lamp will be destroyed. Fluorescent tubes are not suitable for connection to motion sensors or for connection to frequent switching devices. Frequent switching causes shortening of lamp life. Frequent switching is considered to switch the fluorescent lamp to an interval of less than 20 minutes.

More photos available

Technical drawing not available


Download

Technical sheet

Technical sheet LT 54W T5-HQ/840 NBB


Wiring Diagram not available


General information

Model/Description Zářivková trubice
Finish Lineární
Brand/Manufacturer Narva
Nominal service life (h) 35000 h
Colour Ostatní
Socket G5
Dimmable Ano
Energy efficiency class (canceled regulation!) A
Ignition strip Ne
Fast ignition Ne
Starter less operation Ne
Suitable for explosion proof luminaires Ne
Dimmable by conventional dimmers Ne
Název položky LT 54W T5-HQ/840 NBB
Třída energetické účinnosti podle 2019/2015 F

Working conditions

Ambiente temperature for max. luminous flux 35 °C
Burning position Libovolná
Application Pro všeobecné osvětlování
Application Všeobecné osvětlení
Suitable for electronic ballast Ano
Suitable for emergency lighting Ne
For application at low temperatures Ne

EuP Parameters

Average Lifetime B50 (h) 35000 h
Luminescence Life maintenance factor 89,0 %
Number of maximal switching cycles 100000
The rate of premature failures <1 %
Rated service life 35000 h
Energy consumption (AGGR) 54 kWh/1000h

Safety information

Safety instructions www.nbb.cz

Energetic characteristics

Rated efficiency after 100h 99,99 %
Lamp efficacy 92,4 lm/W

Lamp lumen maintenance factor (LLMF)

LLMF after 2.000 hrs 97,5 %
LLMF after 4.000 hrs 95,4 %
LLMF after 6.000 hrs 94,0 %
LLMF after 8.000 hrs 93,0 %
LLMF after 12.000 hrs 91,5 %
LLMF after 16.000 hrs 90,0 %
LLMF after 20.000 hrs 89,0 %

Electrical characteristics

Nominal wattage 54 W
Rated power (W) 54,0 W
Operating voltage (V) 120 V
Type of Voltage AC
Direct connection to the mains Ne
Lamp power 54 W
Nominal current (A) 0,46 A
Total power (W) (light fitting) 54 W

Physical characteristics

Dimensions (mm) Ø16 x 1149 mm
Packing method 25 - 1
Weight gross 125 g
Weight netto 105 g
Splitter protection Ne
Tube diameter 16 mm
Lamp shape Lineární
Length 1149 mm
Internal reflector Ne
Double-walled Ne

Lighting characteristics

Type of spectrum Třípásmové
Color rendering 1B
Light Colour Chladná bílá
Dominant wavelength 544 nm
Luminous flux 5000 lm
Colour temperature 4000 K
Colour rendering index CRI 84 Ra
Full spectrum lamps Ne
Colour of light 840
Colour of light acc. EN 12464-1 Neutral 3300-5300 K
Beam angle Degrees (°) 360 °
Chromaticity coordinates x 0,384
Chromaticity coordinates y 0,382

Environmental characteristics

Mercury content 3,00 mg

Lamp surival factor (LSF)

LSF after 2.000 hrs 99,8 %
LSF after 4.000 hrs 99,6 %
LSF after 6.000 hrs 99,3 %
LSF after 8.000 hrs 99,1 %
LSF after 12.000 hrs 98,7 %
LSF after 16.000 hrs 95,0 %
LSF after 20.000 hrs 79,5 %
